Features
System Compression | Ultra 265, H.265, H.264 |
---|---|
Main Processor | Embedded Processor |
Operating System | Embedded Linux |
IP Camera Input | 8CH |
Video Output |
HDMI: 1920x1080p /60Hz, 1920x1080p /50Hz, 1600x1200 /60Hz, 1280x1024 /60Hz, 1280x720 /60Hz, 1024x768 /60Hz |
Corridor Mode Screen | 3/4/5/7/9 |
Playback Channels | 8CH |
Live View Resolution | 1080p / 960p / 720p / D1 / 2CIF / CIF |
Playback Resolution | 1080p / 960p / 720p / D1 / 2CIF / CIF |
Decoding Capability |
2 x 1080p@30fps, |
Audio In | N/A |
Audio Out | N/A |
2 Way Audio | N/A |
Alarm In | No |
Alarm Out | No |
Network Interface | 1 x RJ-45 10M/100M self-adaptive Ethernet Interface x 1 |
Incoming Bandwidth | 40Mbps |
Outgoing Bandwidth | 40Mbps |
Network Max. Users | 128 Users |
Network Function | P2P, UPnP, NTP, DHCP, PPPoE |
VCA Detection | N/A |
VCA Search | N/A |
Statistical Analysis | N/A |
PoE Ports | 8CH 100 Mbps PoE network interfaces |
PoE Power |
Max 30W for single port |
Supported Standard | IEEE 802.3at, IEEE 802.3af |
Mobile | iPhone, Android |
RS485 | N/A |
USB | Rear panel?2 x USB2.0 |
Power Supply | 52V DC |
Power Consumption | ≤ 5.5 W( without HDD ) |
Internal HDD | 1 x SATA interfaces (up to 8TB for each HDD) |
e-SATA | N/A |
Operating Conditions | 14°F ~ +131°F (-10°C ~ + 55°C), Humidity ≤ 90% RH(non-condensing) |
Dimensions | 260mm × 240mm × 44mm(10.2"×9.4"×1.7") |
Weight | 0.99kg ( 2.18 lb ) |
