ED8004H5-F | H.265 4CH 4K Titanium TVI/AHD/CVI/960H/IP 5-IN-1 DVR

SKU: ED8004H5-F
Stock: 20

Price: $130.00

$119.00

(0.0 on 0) | Write a review

Overview Reviews Tell a Friend

Features

4CH TVI / AHD video input, support 8MP / 5MP / 4MP / 3MP / 1080P / 720P / WD1 recording
4CH CVI video input, support 4MP / 3MP / 1080P / 720P / WD1 recording
4CH DVR support 2 CH IPC 8MP / 5MP / 4MP / 3MP / 1080P / 960P / 720P recording
Adopt standard H.265 high profile compression format to get high-quality video at much lower bit rate
Intuitive and user-friendly Graphics User Interface ( GUI ), window style operation by mouse
Multi-mode recording: manual / timer / motion
Playback : 4CH simultaneously playback
Search: time slice, time, event ( manual, motion ), tag search
Express and flexible backup via USB, network and so on
Pentaplex: preview, record, playback, backup and remote access
DHCP, DDNS, PPPoE network protocol, IE browse and CMS supported
Remote control via IE or CMS : preview, playback, backup, PTZ and configuration
Dual stream technology for local storage with high definition, remote network transmission and remote surveillance with mobile device
Multi-user online simultaneously
Authorization management, log review and device status review
HDMI 4K output, true high resolution display
Support PTZ preset and auto cruise, up to 255 presets and 8 cruises
Support NAT function and QRCode scanning by mobile phone and PAD
Powerful smart phone & Pad surveillance with iOS and Andriod OS

System Compression	H.265 High profile
Main Processor	Embedded Processor
Operating System	Embedded Linux
Video Compatibility	HD-TVI / AHD / HD-CVI
Max. Video Channels	4CH
Video Input	BNC x 4
IP Camera Input	IPC x 2
IPC Resolution	8MP / 5MP / 4MP / 3MP / 1080P / 960P / 720P
IPC Frame Rate	25fps ( PAL ) / 30fps ( NTSC )
Video Interface	HDMI/VGA/CVBS
Video Resolution	TVI/AHD : 8 /5MP/4MP/3MP/1080P/720P/WD1 CVI : 4MP/3MP/1080P/720P/WD1
Multi-Screen Display	N/A
OSD	Yes
Audio In	4CH, RCA
Audio Out	1CH, RCA
2 Way Audio	Take up channel one as an audio input
Recording Resolution	4K/4K Lite/5MP/5MP Lite/4MP/4MP Lite /1080P/720P/WD1
Recording Frame Rate	4K@6fps/7fps (PAL / NTSC) 5MP@12fps (PAL / NTSC) 5MP Lite@20fps (PAL / NTSC) 4MP / 3MP@12fps(PAL) / 15fps (NTSC) 4MP Lite / 1080P / 720P / WD1@25fps (PAL) / 30fps (NTSC)
Recording Encode	N/A
Recording Quality	N/A
Recording Mode	Manual, timer, motion
Recording File Management	N/A
Playback Channels	4CH
Playback Search	Time slice / time / event / tag search
Playback Smart Search	Highlight colors to display the camera record in a certain period of time, different colors refer to different record events
Playback Function	Play, pause, FF, FB, digital zoom, etc
Alarm In	4CH
Alarm Out	1CH
Alarm Mode	Manual, motion, exception
Trigger Events	Record, snap, preset, e-mail, etc.
Network Bandwidth	40/40Mbps (access/transfer)
Network Function	TCP / IP, PPPoE, DHCP, DNS, DDNS, UPnP, NTP, SMTP
Network Max. Users	N/A
Mobile	iPhone, Android
Cellphone Function	N/A
RS485	RS485 x 1, connect to PTZ or keyboard
USB	USB 2.0 × 2
Remote Connections	Optional
Power Supply	DC12V / 4A
Power Consumption	≤ 10W ( without HDD )
Internal HDD	1 x SATA (up to 8TB capacity for each disk),
e-SATA	1 x e-SATA
Operating Conditions	-10 ? 50 ??10% ? 90% humidity
Dimensions	300mm × 248mm × 52mm
