ED8216TEPR | 5MP 16CH 5-IN-1 Hybrid DVR | Up To 12 IPC

SKU: ED8216TEPR
Stock: 19

Price: $299.00

$269.00

(0.0 on 0) | Write a review

Overview Reviews Tell a Friend

Features

16 CH TVI / CVI / AHD video input
16 CH 5MP / 4MP / 4MP lite / 3MP / 1080P / 720P / WD1 recording
4 CH IPC 4MP / 3MP / 1080P / 960P / 720P recording
( Up To 12 IP Cameras Input)
Playback: 16CH simultaneously playback; HDMI 1080P output
Titanium OS
Backup: USB, IE, CMS; support multi-file, file cutting when backup
Pentaplex: live, record, playback, backup and remote operation
DHCP, DDNS, PPPoE Network protocol, IE browse and CMS supported
Dual stream technology; Multi-user online simultaneously
Support PTZ preset and auto cruise, up to 128 presets and 8 cruises
Cell phone: iPhone, Android
Complete SDK function, easy to integrate with other applications
Max HDD: 2 x HDD

Download

System Compression	H.264 High profile
Main Processor	Embedded Processor
Operating System	Embedded Linux
Video Compatibility	HD-TVI / AHD / HD-CVI / 960H / IP
Max. Video Channels	20CH
Video Input	BNC x 16 (TVI/AHD/CVI/960H)
IP Camera Input	IPC x 4 (Max.12 IPC In)
IPC Resolution	4MP / 3MP / 1080P / 960P / 720P
IPC Frame Rate	4MP@30fps
Video Interface	HDMI/VGA/CVBS(SPOT)
Video Resolution	5MP / 4MP / 4MP lite / 3MP / 1080P / 720P / WD1
Multi-Screen Display	N/A
OSD	Yes
Audio In	4CH, RCA
Audio Out	1CH, RCA
2 Way Audio	Take up channel one as an audio input
Recording Resolution	5MP, 4MP, 4MP lite, 3MP,1080P, 720P, WD1
Recording Frame Rate	5MP@10fps, 4MP@15fps, 2MP@30fps
Recording Encode	N/A
Recording Quality	N/A
Recording Mode	Manual,sensor, motion, exception
Recording File Management	Lock, Unlock
Playback Channels	16CH
Playback Search	Time/Calendar Search, Event (motion)
Playback Smart Search	Highlighted date and time to display the channel record
Playback Function	Play, Pause, FF, FB; Digital zoom
Alarm In	4CH
Alarm Out	1CH
Alarm Mode	Manual, sensor, motion, exception
Trigger Events	Record, PTZ move,alarm out,e-mail, etc
Network Bandwidth	IPC × 4 / 24Mbps
Network Function	TCP/IP?PPPoE?DHCP?DNS?DDNS?UPnP?NTP?SMTP?ONVIF?GB28181
Network Max. Users	N/A
Mobile	iPhone, Android
Cellphone Function	Multi-screen surveillance (for certain model), record, snapshot, PTZ control, save the device list
RS485	RS485 x 1, connect to PTZ or keyboard
USB	Rear: 1 x USB3.0, Front: 1 x USB2.0
Remote Connections	Optional
Power Supply	DC 12V
Power Consumption	?10W (without HDD)
Internal HDD	2 x SATA (up to 8TB capacity for each disk)
e-SATA	N/A
Operating Conditions	-10~50°C, 10%~90% (Humidity)
Dimensions	15" x 10.6" x 2.0" (380 x 268 x 52mm)
